Technical Parameter
| Conventional parameters | |
|---|---|
| Equipment Model | SCP300C2 |
| Model Abbreviation | 300 |
| Engine | |
| Model | Cummins8.3 Ⅲ |
| Whole machine parameters | |
| Total Weight of the Machine (kg) | 43100 |
| Rated Lifting Capacity (kg) | 30000 |
| Load Center Distance (mm) | 1200 |
| Maximum Travel Speed (Empty/Loaded) (km/h) | 26/28 |
| Maximum Lifting Speed (mm/s) | 300/350 |
| Maximum Lowering Speed (mm/s) | 400/350 |
| Maximum Gradeability (%) | 18/33 |
| Wheelbase (Front/Rear) (mm) | 2472/2455 |
| Ground Clearance (mm) | 300 |
| External Dimensions | |
| Maximum Fork Height (Standard Mast) (mm) | 4000 |
| Free Lift Height (Standard Mast) (mm) | 920~2850 |
| Thickness × Width × Length (Fork) (mm) | 2400×300×110 |
| Mast Tilt Angle (Forward/Backward) (°) | 5/10 |
| Overall Length (to Vertical Face of Fork) (mm) | 9190 |
| Width (Frame Width) (mm) | 3520 |
| Maximum Lifting Height of Fork (mm) | 4360 |
| Minimum Turning Radius (mm) | 715 |
| Mast Height (mm) | 4400/6345 |
