Technical Parameter
| Conventional parameters | |
|---|---|
| Equipment Model | SCP320C1 |
| Model Abbreviation | 320 |
| Engine | |
| Model | VOLVO TAD760VE |
| Rated Power (kW) | 181 |
| Maximum Torque (N·m) | 2300 |
| Whole machine parameters | |
| Total Weight of the Machine (kg) | 43000 |
| Rated Lifting Capacity (kg) | 32000 |
| Maximum Travel Speed (Empty/Loaded) (km/h) | 30/26 |
| Maximum Lifting Speed (mm/s) | 400 |
| Maximum Lowering Speed (mm/s) | 400 |
| Maximum Gradeability (%) | 33 |
| Hook Traction Force (kN) | 186 |
| Wheelbase (Front/Rear) (mm) | 4800（Wheelbase） |
| External Dimensions | |
| Maximum Fork Height (Standard Mast) (mm) | 6345 |
| Free Lift Height (Standard Mast) (mm) | 4400 |
| Thickness × Width × Length (Fork) (mm) | 2400×300×125 |
| Mast Tilt Angle (Forward/Backward) (°) | 5/10 |
| Overall Length (to Vertical Face of Fork) (mm) | 9587 |
| Width (Frame Width) (mm) | 3450 |
| Maximum Lifting Height of Fork (mm) | 4000 |
| Minimum Turning Radius (mm) | 6800 |
